NICHICON

UVZ0J221MDD

Datasheet

220uF 6.3V Aluminum Electrolytic Capacitor, Radial, 105°C, 145mA

Nichicon

UVZ0J221MDD

Name: UVZ0J221MDD Nichicon
Brand: Nichicon
SKU: UVZ0J221MDD

220uF 6.3V Aluminum Electrolytic Capacitor, Radial, 105°C, 145mA

Aluminum electrolytic capacitor with 220µF capacitance and 6.3V DC rated voltage, offering 20% tolerance. Features a radial package with 5mm diameter, 11mm height, and 2mm lead pitch, suitable for through-hole PCB mounting. Operates across a wide temperature range from -55°C to 105°C, with a 1000-hour life expectancy at rated conditions. Dissipation factor is 0.28%, leakage current is 41.58µA, and ripple current handling is 145mA. RoHS compliant and lead-free.

PackageRadial

Voltage6.3V

Capacitance220uF

Voltage Rating6.3V

Quick Jump:

Technical Specifications

Nichicon UVZ0J221MDD technical specifications.

General

Capacitance	220uF
Package/Case	Radial
Construction	RADIAL
Diameter	5mm
Dielectric Material	Aluminium
Dissipation Factor	0.28%
Height	11mm
Lead Diameter	0.5mm
Lead Free	Lead Free
Lead Pitch	2mm
Leakage Current	41.58uA
Length	11mm
Life (Hours)	1000Hour
Max Operating Temperature	105°C
Min Operating Temperature	-55°C
Mount	Through Hole, PCB
Package Quantity	200
Packaging	Bulk
Radiation Hardening	No
Ripple Current	145mA
RoHS Compliant	Yes
Series	VZ
Termination	Radial
Tolerance	20%
Voltage	6.3V
Voltage Rating	6.3V
DC Rated Voltage	6.3V
