Aluminum electrolytic capacitor, 22µF capacitance, 50V DC rated voltage, 20% tolerance. Features a cylindrical SMD/SMT package with 8mm diameter and 5.4mm height, designed for surface mounting. Offers a ripple current of 52mA, leakage current of 3µA, and a dissipation factor of 0.12%. Operates within a temperature range of -40°C to 85°C with a lifespan of 2000 hours at rated conditions.
PackageSMD/SMT
Voltage50V
Capacitance22uF
Voltage Rating50V
Quick Jump:
Technical Specifications
Nichicon UWX1H220MCL1GB technical specifications.
General
| Capacitance | 22uF |
| Package/Case | SMD/SMT |
| Construction | Cylindrical |
| Diameter | 8mm |
| Dielectric Material | Aluminium |
| Dissipation Factor | 0.12% |
| Height | 5.4mm |
| Height - Seated (Max) | 0.213inch |
| Lead Free | Lead Free |
| Lead Pitch | 2.3mm |
| Leakage Current | 3uA |
| Length | 5.4mm |
| Life (Hours) | 2000Hour |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Package Quantity | 1 |
| Packaging | Cut Tape |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Ripple Current | 52mA |
| Ripple Current (AC) | 52mA |
| RoHS Compliant | Yes |
| Series | WX |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage | 50V |
| Voltage Rating | 50V |
| DC Rated Voltage | 50V |
Compliance
| RoHS | Compliant |
Datasheet
Nichicon UWX1H220MCL1GB Datasheet
Download the complete datasheet for Nichicon UWX1H220MCL1GB to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
