DPO-0.5-330

FIXED IND 330UH 500MA 265 MOHM

PackageRadial

MountingThrough Hole

Inductance330uH

Quick Jump:

Nuvotem DPO-0.5-330 technical specifications.

Package/Case

Radial

DC Resistance (DCR)

265mR

Inductance

330uH

Max Operating Temperature

125°C

Min Operating Temperature

-40°C

Mount

Through Hole

Packaging

Tray

RoHS Compliant

Yes

Series

Shielding

Unshielded

Test Frequency

10kHz

RoHS

Compliant

This datasheet cannot be embedded due to technical restrictions.
