Frequency100MHz
PackageSC
MountingSurface Mount
PolarityPNP
Quick Jump:
Technical Specifications
NXP BC856BT115 technical specifications.
General
Package/Case
SC
Collector Base Voltage (VCBO)
80V
Collector Emitter Breakdown Voltage
65V
Collector Emitter Voltage (VCEO)
65V
Collector-emitter Voltage-Max
400mV
Continuous Collector Current
-100mA
Emitter Base Voltage (VEBO)
-5V
Frequency
100MHz
Gain Bandwidth Product
100MHz
hFE Min
220
Max Breakdown Voltage
65V
Max Collector Current
100mA
Max Operating Temperature
150°C
Min Operating Temperature
-65°C
Max Power Dissipation
150mW
Mount
Surface Mount
Number of Elements
1
Package Quantity
1
Packaging
Tape and Reel
Polarity
PNP
Power Dissipation
150mW
Radiation Hardening
No
Transition Frequency
100MHz
Compliance
RoHS
Compliant
Datasheet
NXP BC856BT115 Datasheet
Download the complete datasheet for NXP BC856BT115 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
