PackageRadial
Resistance5kR
Voltage Rating625V
MountingChassis Mount, Bolt
Quick Jump:
Technical Specifications
Ohmite D25K5K0 technical specifications.
General
Package/Case
Radial
Diameter
7.94mm
Length
50.8mm
Material
Ceramic
Max Operating Temperature
350°C
Min Operating Temperature
25°C
Max Power Dissipation
25W
Mount
Chassis Mount, Bolt
Packaging
Bulk
Resistance
5kR
RoHS Compliant
No
Series
Dividohm®210
Termination
Lug
Tolerance
10%
Voltage Rating
625V
Compliance
RoHS
Not Compliant
Datasheet
Ohmite D25K5K0 Datasheet
Download the complete datasheet for Ohmite D25K5K0 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
