PackageRadial
Resistance1.5kR
Voltage Rating1.625kV
MountingChassis Mount, Bolt
Quick Jump:
Technical Specifications
Ohmite D50K1K5E technical specifications.
General
Package/Case
Radial
Depth
14.3mm
Diameter
7.94mm
Length
101.6mm
Max Operating Temperature
350°C
Min Operating Temperature
25°C
Max Power Dissipation
50W
Mount
Chassis Mount, Bolt
Packaging
Bulk
Reach SVHC Compliant
Unknown
Resistance
1.5kR
Resistance Tolerance
10%
Resistor Type
Wirewound
RoHS Compliant
Yes
Series
Dividohm®210
Termination
Lug
Tolerance
10%
Voltage Rating
1.625kV
DC Rated Voltage
1.62kV
Compliance
RoHS
Compliant
Datasheet
Ohmite D50K1K5E Datasheet
Download the complete datasheet for Ohmite D50K1K5E to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
