Ohmite
L25J100K
Fixed Resistor, Wire Wound, 25W, 100000ohm, 625V, 5% +/-Tol, 260ppm/Cel, Chassis Mount
PackageRadial
Resistance100kR
Voltage Rating625V
MountingBrackets, Bolt
Quick Jump:
Technical Specifications
Ohmite L25J100K technical specifications.
General
Package/Case
Radial
Depth
14.3mm
Diameter
14.3mm
Features
Flame Retardant Coating
Inside Diameter
7.95mm
Lead/Base Style
Solder
Length
50.8mm
Max Operating Temperature
350°C
Min Operating Temperature
25°C
Max Power Dissipation
25W
Mount
Brackets, Bolt
Package Quantity
1
Packaging
Bulk
Resistance
100kR
RoHS Compliant
No
Series
270
Termination
Lug
Tolerance
5%
Voltage Rating
625V
DC Rated Voltage
625V
Compliance
RoHS
Not Compliant
Datasheet
Ohmite L25J100K Datasheet
Download the complete datasheet for Ohmite L25J100K to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
