PackageTO-220-2
Resistance30R
Voltage Rating150V
MountingThrough Hole
Quick Jump:
Technical Specifications
Ohmite TN15P30R0FE technical specifications.
General
Package/Case
TO-220-2
Height
0.701inch
Lead Free
Lead Free
Lead Pitch
5.1mm
Length
0.394inch
Max Operating Temperature
150°C
Min Operating Temperature
0°C
Max Power Dissipation
15W
Mount
Through Hole
Number of Terminations
2
Package Quantity
100
Packaging
Rail/Tube
Resistance
30R
Resistance Tolerance
1%
Resistor Type
Thin Film
RoHS Compliant
Yes
Series
TN
Terminal Pitch
5.1mm
Termination
Radial
Tolerance
1%
Voltage Rating
150V
DC Rated Voltage
200V
Width
10mm
Compliance
RoHS
Compliant
Datasheet
Ohmite TN15P30R0FE Datasheet
Download the complete datasheet for Ohmite TN15P30R0FE to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
