Technical Specifications
Panasonic DB2X20600L technical specifications.
General
| Average Rectified Current | 1A |
| Forward Current | 1A |
| Lead Free | Lead Free |
| Max Forward Surge Current (Ifsm) | 3A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Repetitive Reverse Voltage (Vrrm) | 20V |
| Max Reverse Current | 100uA |
| Max Reverse Voltage (DC) | 20V |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | No |
| Reverse Recovery Time | 6ns |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
Panasonic DB2X20600L Datasheet
Download the complete datasheet for Panasonic DB2X20600L to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
