Technical Specifications
Panasonic ESB-33133 technical specifications.
General
Actuator Type
Lever
Contact Current Rating
200mA
Contact Plating
Silver
Current Rating
200mA
Lead Free
Lead Free
Length
10mm
Max Operating Temperature
80°C
Min Operating Temperature
-30°C
Mount
Through Hole
Orientation
Vertical
Package Quantity
100
Packaging
Bulk
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
ESB33
Switch Function
On-On
Termination
PC Pin
Throw Configuration
DPDT
DC Rated Voltage
14V
Width
10mm
Compliance
RoHS
Compliant
Datasheet
Panasonic ESB-33133 Datasheet
Download the complete datasheet for Panasonic ESB-33133 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
