Technical Specifications
Rohm RLR4004TE-21 technical specifications.
General
| Average Rectified Current | 800mA |
| Forward Current | 800mA |
| Lead Free | Lead Free |
| Max Forward Surge Current (Ifsm) | 20A |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Repetitive Reverse Voltage (Vrrm) | 400V |
| Max Reverse Current | 10uA |
| Max Reverse Voltage (DC) | 400V |
| Max Surge Current | 20A |
| Mount | Surface Mount |
| Package Quantity | 5000 |
| Packaging | Tape and Reel |
| Peak Non-Repetitive Surge Current | 20A |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Reverse Voltage | 400V |
| RoHS Compliant | Yes |
| Termination | SMD/SMT |
Compliance
| RoHS | Compliant |
Datasheet
Rohm RLR4004TE-21 Datasheet
Download the complete datasheet for Rohm RLR4004TE-21 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
