SCHNEIDER

LADN22

Datasheet

4-Pin Relay Socket, 690V AC, 10A, Clip Mount, 2-Pole, 4-Throw

Schneider

LADN22

Name: LADN22 Schneider
Brand: Schneider
SKU: LADN22

4-Pin Relay Socket, 690V AC, 10A, Clip Mount, 2-Pole, 4-Throw

This 4-pin relay socket is designed for use in high-voltage applications, with a maximum operating voltage of 690V AC and a current rating of 10A. It features a clip mount design for easy installation and a 2-pole, 4-throw configuration to provide reliable switching performance. The socket operates within a temperature range of -5°C to 60°C, making it suitable for use in a variety of environments. It meets the safety standards of several international organizations, including UL, CSA, VDE, IEC, and EN, but is not compliant with the RoHS directive.

Package600

Current Rating10A

MountingClip

Quick Jump:

Technical Specifications

Schneider LADN22 technical specifications.

General

Approvals	UL, CSA, VDE, IEC, EN
Package/Case	600
Contact Current Rating	10A
Current Rating	10A
Max Operating Temperature	60°C
Min Operating Temperature	-5°C
Mount	Clip
Number of Contacts	4
Number of Poles	2
Reach SVHC Compliant	Unknown
RoHS Compliant	No
Termination	Screw
Throw Configuration	4P
Voltage Rating (AC)	690V
