Illuminated fuse holder with a 10A current rating and 250V AC/DC voltage rating, designed for 3AG fuses (1-1/4" L x 1/4" Dia). Features a thermoplastic body in black with tin-plated contacts, suitable for vertical PCB mounting via through-hole termination. Operating temperature range is -40°C to 85°C, with UL94 V-0 flammability rating. Approvals include UL and CSA.
Voltage250V
Voltage Rating250V
Current Rating10A
MountingVertical, PCB, Through Hole
Quick Jump:
Technical Specifications
Schurter 0031.3822 technical specifications.
General
Approvals
UL, CSA
Body Material
Thermoplastic
Color
Black
Contact Material
Tin
Contact Plating
Tin
Current Rating
10A
Flammability Rating
UL94 V-0
Fuse Current
10A
Fuse Size
3AG, 1-1/4" L x 1/4" Dia (31.8mm x 6.35mm)
Illumination Type
Illuminated
Lead Free
Lead Free
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Vertical, PCB, Through Hole
Number of Circuits
1
Number of Poles
1
Orientation
Vertical
Package Quantity
100
Packaging
Bulk
Reach SVHC Compliant
No
Series
FAC
Termination
PC Pin
Voltage
250V
Voltage Rating
250V
Voltage Rating (AC)
250V
DC Rated Voltage
250V
Weight
0.317466oz
Compliance
RoHS
Compliant
Datasheet
Schurter 0031.3822 Datasheet
Download the complete datasheet for Schurter 0031.3822 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
