Schurter
1301.9502
Keypad Switch, 1 Switches, SPST, Momentary-tactile, 0.05A, 12VDC, 2.1N, 4 PCB Hole Cnt, Solder Terminal, Through Hole-right Angle,
MountingThrough Hole
Quick Jump:
Technical Specifications
Schurter 1301.9502 technical specifications.
General
Actuator Type
Standard
Illumination Type
Non-Illuminated, Illuminated
Max Current Rating
50mA
Max Operating Temperature
70°C
Min Operating Temperature
-20°C
Max Voltage Rating (DC)
12V
Mechanical Life
100000Cycles
Mount
Through Hole
Operating Force
1.6N
Package Quantity
2000
Packaging
Bulk
Radiation Hardening
No
Ratings
IP40
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
LPV
Switch Function
Off-Mom
Switch Travel
0.25mm
Termination
PC Pin
Throw Configuration
SPST
Weight
0.018695oz
Compliance
RoHS
Compliant
Datasheet
Schurter 1301.9502 Datasheet
Download the complete datasheet for Schurter 1301.9502 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
