Technical Specifications
Siemens 3RF23101AA04 technical specifications.
General
Approvals
UL, CSA, CE, GOST
Package/Case
460
Contact Current Rating
10A
Current Rating
10A
Depth
94mm
Height
100mm
Isolation Voltage
600V
Length
22.5mm
Load Current
10.5A
Max Input Voltage
460V
Min Input Voltage
230V
Max Operating Temperature
60°C
Min Operating Temperature
-25°C
Max Output Voltage
30V
Mount
DIN Rail, Panel
Number of Poles
1
Termination
Screw
Voltage Rating (AC)
460V
Width
0.886inch
Compliance
RoHS
Not Compliant
Datasheet
Siemens 3RF23101AA04 Datasheet
Download the complete datasheet for Siemens 3RF23101AA04 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
