Single-output AC/DC power supply providing 24V at 2.5A, with a maximum output power of 60W. Features wide AC input voltage range (85-240V) and DC input voltage range (110-300V), achieving 88% efficiency. Operates across a temperature range of -20°C to 70°C and mounts via DIN rail. Dimensions are 72mm (length) x 55mm (width) x 90mm (height), with a weight of 0.25kg. Rated IP20.
Package120
MountingDIN Rail
Power60W
Quick Jump:
Technical Specifications
Siemens 6EP1332-1SH43 technical specifications.
General
Package/Case
120
Current - Output 1
2.5A
Depth
90mm
Efficiency
88%
Height
90mm
Length
72mm
Max Input Voltage (AC)
240V
Min Input Voltage (AC)
85V
Max Input Voltage (DC)
300V
Min Input Voltage (DC)
110V
Max Input Voltage
240V
Min Input Voltage
85V
Max Operating Temperature
70°C
Min Operating Temperature
-20°C
Max Output Current
2.5A
Max Output Power
60W
Mount
DIN Rail
Nominal Output Voltage
24V
Number of Outputs
1
Output Current
2.5A
Output Power
60W
Output Voltage
24V
Ratings
IP20
Reach SVHC Compliant
No
Voltage - Output 1
24V
Weight
0.25kg
Width
55mm
Compliance
RoHS
Compliant
