Current Rating17.5A
MountingScrew, DIN Rail
Quick Jump:
Technical Specifications
Siemens 6EP19332EC41 technical specifications.
General
Current Rating
17.5A
Depth
120mm
Efficiency
97.5%
Height
125mm
Length
125mm
Max Operating Temperature
60°C
Min Operating Temperature
0°C
Max Output Current
15A
Max Output Voltage
24.72V
Min Output Voltage
23.28V
Mount
Screw, DIN Rail
Number of Outputs
1
Operating Supply Voltage
24V
Output Current
15A
Output Voltage
24V
Ratings
IP20
Weight
1kg
Width
120mm
Compliance
RoHS
Compliant
Datasheet
Siemens 6EP19332EC41 Datasheet
Download the complete datasheet for Siemens 6EP19332EC41 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
