Frequency156.25MHz
PackageSMD/SMT
Current Rating98mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Silicon Labs 531FC156M250DG technical specifications.
General
Package/Case
SMD/SMT
Current Rating
98mA
Depth
5mm
Frequency
156.25MHz
Frequency Stability
7ppm
Height
1.8mm
Length
7mm
Max Duty Cycle
55%
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Current
98mA
Max Supply Voltage
2.5V
Min Supply Voltage
2.5V
Mount
Surface Mount
Output Format
LVDS
Package Quantity
50
Packaging
Tray
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
SI531
Termination
SMD/SMT
Width
5mm
Compliance
RoHS
Compliant
Datasheet
Silicon Labs 531FC156M250DG Datasheet
Download the complete datasheet for Silicon Labs 531FC156M250DG to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
