8-bit CMOS microcontroller featuring 4096 bytes of RAM and 65536 words of FLASH ROM. This industrial-grade microcontroller operates within a temperature range of -40°C to 85°C, with a nominal supply voltage of 2.4V (1.8V to 3.6V). It offers 11 I/O lines and includes an Analog-to-Digital Converter (ADC). Packaged in a 36-terminal QFN (R-XQCC-N36) with dimensions of 5x6mm, it supports a maximum clock frequency of 32 MHz.
Frequency25
Quick Jump:
Technical Specifications
Silicon Labs SI1062-A-GM technical specifications.
General
Max Operating Temperature
85
Number of Terminals
36
Min Operating Temperature
-40
Terminal Position
QUAD
JEDEC Package Code
R-XQCC-N36
Width
5
Length
6
Temperature Grade
INDUSTRIAL
Supply Voltage-Nom
2.4
Supply Voltage-Min
1.8
Supply Voltage-Max
3.6
Clock Frequency-Max
32
uPs/uCs/Peripheral ICs Type
MICROCONTROLLER
Number of I/O Lines
11
External Data Bus Width
0
Address Bus Width
0
Bit Size
8
Speed
25
ROM Programmability
FLASH
ROM (words)
65536
RAM (bytes)
4096
PWM Channels
NO
Has ADC
YES
DMA Channels
NO
DAC Channels
NO
Compliance
RoHS
Yes
HTS Code
8542.31.00.01
REACH
Compliant
Military Spec
False
