Package100
MountingChassis Mount, Panel
Quick Jump:
Technical Specifications
SL Power HBB15-1.5-A+ technical specifications.
General
Approvals
UL, CSA, TUV, IEC
Package/Case
100
Current - Output 1
1.5A
Current - Output 2
1.5A
Depth
123.95mm
Efficiency
45%
Length
177.8mm
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Output Current
1.5A
Max Power Dissipation
41W
Mount
Chassis Mount, Panel
Number of Outputs
2
Output Voltage
-15V
Package Quantity
5
Series
Linear BB
Voltage - Output 1
15V
Voltage - Output 2
-15V
Weight
1.81kg
Compliance
RoHS
Not Compliant
Datasheet
SL Power HBB15-1.5-A+ Datasheet
Download the complete datasheet for SL Power HBB15-1.5-A+ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
