Struthers-Dunn
A275KXX91-120VAC
Contactor, Motor Reversing, 15A, 3PDM-NO, 120VAC, 4 Aux contacts each SPDT(2per coil)
Current Rating15A
MountingVertical
Quick Jump:
Technical Specifications
Struthers-Dunn A275KXX91-120VAC technical specifications.
General
Approvals
CSA
Coil Power
16.8W
Coil Voltage (AC)
120V
Contact Current Rating
15A
Contact Material
Silver
Current Rating
15A
Depth
0.157inch
Length
2.984inch
Max Operating Temperature
74°C
Min Operating Temperature
-34°C
Mount
Vertical
Number of Poles
3
Reach SVHC Compliant
Unknown
RoHS Compliant
No
Termination
Quick Connect
Width
3.37inch
Compliance
RoHS
Compliant
Datasheet
Struthers-Dunn A275KXX91-120VAC Datasheet
Download the complete datasheet for Struthers-Dunn A275KXX91-120VAC to view detailed technical specifications.
