Single 3-to-8 CMOS decoder/demultiplexer IC featuring 8 output lines and 3 input lines. Operates with a 5V supply voltage, supporting a range of 4.5V to 5.5V. Offers a 12ns propagation delay and 100MHz bandwidth. Packaged in a 16-pin PDIP with gold contact plating, suitable for through-hole mounting. RoHS compliant with a maximum operating temperature of 125°C.
PackagePDIP
MountingThrough Hole
PolarityInverting
Power1.15W
Quick Jump:
Technical Specifications
Texas Instruments CD74ACT138E technical specifications.
General
| Bandwidth | 100MHz |
| Package/Case | PDIP |
| Contact Plating | Gold |
| Height | 4.57mm |
| High Level Output Current | -24mA |
| Independent Circuits | 1 |
| Lead Free | Lead Free |
| Length | 19.3mm |
| Logic Function | Demultiplexer, Decoder |
| Low Level Output Current | 24mA |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Number of Bits | 8 |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Gates | 1 |
| Number of Input Lines | 3 |
| Number of Inputs | 3 |
| Number of Output Lines | 8 |
| Number of Outputs | 8 |
| Operating Supply Voltage | 5V |
| Package Quantity | 25 |
| Packaging | Rail/Tube |
| Polarity | Inverting |
| Power Dissipation | 1.15W |
| Propagation Delay | 12ns |
| Quiescent Current | 8uA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 74ACT |
| Supply Type | Single |
| Technology | CMOS |
| Turn-On Delay Time | 12ns |
| Weight | 0.03357oz |
| Width | 6.35mm |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments CD74ACT138E Datasheet
Download the complete datasheet for Texas Instruments CD74ACT138E to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
