High-performance h-bridge motor driver for brushed DC motors, featuring a 38V maximum supply voltage and 2.8A output current. This integrated circuit offers precise current feedback and operates over a wide temperature range of -40°C to 85°C. The compact 16-QFN package, measuring 4.15mm x 4.15mm x 0.75mm, is designed for surface mounting. It utilizes a parallel interface for control and is RoHS compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Texas Instruments DRV8801RTYT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | QFN |
| Height | 0.75mm |
| Interface | Parallel |
| Lead Free | Lead Free |
| Length | 4.15mm |
| Max Collector Current | 1.8A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 38V |
| Min Supply Voltage | 8V |
| Motor Type | Brushed |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Operating Supply Voltage | 32V |
| Output Current | 2.8A |
| Output Voltage | 400mV |
| Package Quantity | 250 |
| Packaging | Tape and Reel |
| Quiescent Current | 3.2mA |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | DRV8801 |
| Supply Current | 6mA |
| Technology | DMOS |
| Thickness | 750um |
| Width | 4.15mm |
| RoHS | Compliant |
