50mA, 5V fixed output positive linear voltage regulator with 2% accuracy. Features a low 200mV dropout voltage and 15µA quiescent current. Operates from a 4V to 40V input range with a maximum supply voltage of 60V. Housed in an 8-SOIC package for surface mounting, this regulator offers reverse voltage protection and a wide operating temperature range of -40°C to 125°C.
PackageSOIC
Voltage5V
MountingSurface Mount
PolarityPositive
Quick Jump:
Technical Specifications
Texas Instruments LM2936M-5.0/NOPB technical specifications.
General
Accuracy
2%
Package/Case
SOIC
Dropout Voltage
200mV
Height
1.45mm
Lead Free
Lead Free
Length
4.9mm
Max Input Voltage
40V
Min Input Voltage
4V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
50mA
Max Output Voltage
5V
Max Supply Current
2.5mA
Max Supply Voltage
60V
Min Supply Voltage
5.5V
Mount
Surface Mount
Nominal Output Voltage
5V
Number of Outputs
1
Number of Regulators
1
Output Configuration
Positive
Output Current
50mA
Output Type
Fixed
Output Voltage
5V
Output Voltage Accuracy
2%
Package Quantity
95
Packaging
Rail/Tube
Polarity
Positive
Power Supply Rejection Ratio (PSRR)
60dB
Quiescent Current
15uA
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Termination
SMD/SMT
Voltage
5V
Width
3.9mm
Compliance
RoHS
Compliant
Datasheet
Texas Instruments LM2936M-5.0/NOPB Datasheet
Download the complete datasheet for Texas Instruments LM2936M-5.0/NOPB to view detailed technical specifications.
