Texas Instruments
LM4041DIM3-1.2
Fixed & adjustable, 45-µA, precision micropower shunt voltage reference 3-SOT-23 -40 to 85
PackageSOT-23
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments LM4041DIM3-1.2 technical specifications.
General
Package/Case
SOT-23
Cathode Current
70uA
Lead Free
Contains Lead
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Voltage
1.225V
Min Output Voltage
1.225V
Max Power Dissipation
306mW
Mount
Surface Mount
Output Current
12mA
Output Type
Fixed
Output Voltage
1.225V
Package Quantity
1
Packaging
Tape and Reel
Reach SVHC Compliant
No
Reference Type
Shunt
Reference Voltage
1.225V
RoHS Compliant
No
Tolerance
1%
Compliance
RoHS
Not Compliant
Datasheet
Texas Instruments LM4041DIM3-1.2 Datasheet
Download the complete datasheet for Texas Instruments LM4041DIM3-1.2 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
