Dual CMOS operational amplifier featuring a 1.4MHz gain bandwidth product and 1.1V/µs slew rate. This general-purpose amplifier offers a wide operating voltage range from 4.75V to 15.5V, with a low input bias current of 0.002pA and 1mV input offset voltage. Designed for surface mounting in an 8-SOIC package, it provides 40mA output current per channel and a voltage gain of 126.02dB, with a common mode rejection ratio of 63dB. Operating temperature range spans from -40°C to 85°C.
PackageSOIC
Current750uA
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments LMC662CM technical specifications.
General
| Amplifier Type | GENERAL PURPOSE |
| Bandwidth | 1.4MHz |
| Package/Case | SOIC |
| Common Mode Rejection Ratio | 63dB |
| Gain Bandwidth Product | 1.4MHz |
| Input Bias Current | 0.002pA |
| Input Offset Voltage (Vos) | 1mV |
| Lead Free | Contains Lead |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 15.5V |
| Min Supply Voltage | 4.75V |
| Mount | Surface Mount |
| Number of Amplifiers | 2 |
| Number of Channels | 2 |
| Number of Circuits | 2 |
| Operating Supply Current | 750uA |
| Output Current | 40mA |
| Output Current per Channel | 40mA |
| Package Quantity | 95 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Slew Rate | 1.1V/µs |
| Supply Current | 750uA |
| Technology | CMOS |
| Voltage Gain | 126.02dB |
Compliance
| RoHS | Not CompliantNo |
Datasheet
Texas Instruments LMC662CM Datasheet
Download the complete datasheet for Texas Instruments LMC662CM to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
