1.8V fixed positive LDO regulator with 800mA output current. Features a low dropout voltage of 240mV and a maximum input voltage of 7V. Operates across a wide temperature range from -40°C to 125°C. Packaged in a SOT-223 surface mount case, supplied on tape and reel.
PackageSOT-223
Voltage1.8V
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments LP3961EMP-1.8 technical specifications.
General
Package/Case
SOT-223
Dropout Voltage
240mV
Lead Free
Contains Lead
Max Input Voltage
7V
Min Input Voltage
2.5V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
800mA
Max Output Voltage
1.8V
Max Supply Current
15mA
Max Supply Voltage
7V
Min Supply Voltage
2.5V
Mount
Surface Mount
Nominal Output Voltage
1.8V
Number of Outputs
1
Number of Regulators
1
Output Configuration
Positive
Output Current
800mA
Output Type
Fixed
Output Voltage
1.8V
Package Quantity
1000
Packaging
Tape and Reel
Quiescent Current
9mA
Reach SVHC Compliant
No
RoHS Compliant
No
Voltage
1.8V
Compliance
RoHS
Not Compliant
