2-bit bidirectional voltage level translator for I2C/SMBus applications, operating up to 400 kHz. Features include a 1.5 ns propagation delay and 1.4 ns turn-on delay, supporting a wide supply voltage range from 0V to 5V. This integrated circuit offers two channels with 64mA output current, housed in an 8-VSSOP package with SMD/SMT termination. Designed for reliability, it operates across a temperature range of -40°C to 85°C and is RoHS compliant.
Frequency400kHz
PackageVSSOP
Quick Jump:
Technical Specifications
Texas Instruments PCA9306DCUR technical specifications.
General
Package/Case
VSSOP
Channel Type
Bidirectional
Frequency
400kHz
Lead Free
Lead Free
Logic Function
Translator
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
5V
Min Supply Voltage
0V
Number of Channels
2
Number of Circuits
1
Number of Inputs
2
Number of Outputs
2
Output Current
64mA
Package Quantity
3000
Packaging
Tape and Reel
Propagation Delay
1.5ns
Reach SVHC Compliant
No
RoHS Compliant
Yes
Termination
SMD/SMT
Thickness
850um
Turn-On Delay Time
1.4ns
Weight
0.000339oz
Compliance
RoHS
Compliant
Datasheet
Texas Instruments PCA9306DCUR Datasheet
Download the complete datasheet for Texas Instruments PCA9306DCUR to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
