Six-channel CMOS inverter with Schmitt-trigger inputs, operating from a 2V to 5.5V supply. Features a 10.6ns propagation delay and 8mA output current. Packaged in a 14-SOIC surface-mount case with dimensions of 8.65mm length, 3.91mm width, and 1.58mm height. RoHS compliant with a minimum operating temperature of -40°C and a maximum of 125°C.
PackageSOIC
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments SN74AHC14D technical specifications.
General
Package/Case
SOIC
Height
1.58mm
High Level Output Current
-8mA
Input Type
SCHMITT TRIGGER
Lead Free
Lead Free
Length
8.65mm
Logic Function
Buffer, Inverter, Schmitt Trigger
Low Level Output Current
8mA
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Supply Voltage
5.5V
Min Supply Voltage
2V
Mount
Surface Mount
Number of Bits
6
Number of Circuits
6
Number of Elements
6
Number of Gates
6
Number of Inputs
1
Output Current
8mA
Package Quantity
50
Packaging
Rail/Tube
Propagation Delay
10.6ns
Quiescent Current
2uA
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Schmitt Trigger Input
Yes
Series
74AHC
Technology
CMOS
Turn-On Delay Time
12ns
Weight
0.004564oz
Width
3.91mm
Compliance
RoHS
Compliant
Datasheet
Texas Instruments SN74AHC14D Datasheet
Download the complete datasheet for Texas Instruments SN74AHC14D to view detailed technical specifications.
