Octal bus transceiver and register featuring 3-state outputs. This CMOS logic IC operates bidirectionally across 8 channels, with an operating supply voltage of 5V, ranging from 2V to 6V. It offers a high level output current of -7.8mA and a low level output current of 7.8mA, with a propagation delay of 410ns. Packaged in a 24-PDIP for through-hole mounting, this RoHS compliant component functions within a temperature range of -40°C to 85°C.
PackagePDIP
MountingThrough Hole
PolarityNon-Inverting
Quick Jump:
Technical Specifications
Texas Instruments SN74HC652NT technical specifications.
General
| Package/Case | PDIP |
| Direction | Bidirectional |
| Height | 4.57mm |
| High Level Output Current | -7.8mA |
| Lead Free | Lead Free |
| Length | 31.64mm |
| Logic Function | Transceiver, Inverting |
| Low Level Output Current | 7.8mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 6V |
| Min Supply Voltage | 2V |
| Mount | Through Hole |
| Number of Bits | 8 |
| Number of Bits per Element | 8 |
| Number of Channels | 8 |
| Number of Circuits | 8 |
| Number of Elements | 1 |
| Number of Outputs | 8 |
| Operating Supply Voltage | 5V |
| Output Type | 3-STATE |
| Package Quantity | 15 |
| Packaging | Rail/Tube |
| Polarity | Non-Inverting |
| Propagation Delay | 410ns |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 74HC |
| Technology | CMOS |
| Termination | Through Hole |
| Turn-On Delay Time | 265ns |
| Weight | 0.061853oz |
| Width | 6.73mm |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments SN74HC652NT Datasheet
Download the complete datasheet for Texas Instruments SN74HC652NT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
