Dual operational amplifier featuring a 1.3MHz bandwidth and 3.6V/µs slew rate. This general-purpose amplifier offers a 1.7MHz gain bandwidth product and 87.23dB voltage gain. Designed for single-supply operation, it supports a voltage range of 3V to 16V with a maximum supply current of 3.2mA. The component boasts a low input bias current of 60pA and operates across a wide temperature range from -40°C to 85°C. Packaged in an 8-PDIP, this RoHS compliant IC is ideal for various amplification applications.
PackageP
Current4mA
Power1W
Quick Jump:
Technical Specifications
Texas Instruments TLC272CP technical specifications.
General
| Amplifier Type | GENERAL PURPOSE |
| Bandwidth | 1.3MHz |
| Package/Case | P |
| Common Mode Rejection Ratio | 65dB |
| Gain Bandwidth Product | 1.7MHz |
| Height | 4.57mm |
| Input Bias Current | 60pA |
| Input Offset Voltage (Vos) | 10mV |
| Lead Free | Lead Free |
| Length | 9.81mm |
| Max I/O Voltage | 10mV |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 1W |
| Max Supply Current | 3.2mA |
| Max Supply Voltage | 16V |
| Min Supply Voltage | 3V |
| Nominal Gain Bandwidth Product | 1.7MHz |
| Number of Amplifiers | 2 |
| Number of Channels | 2 |
| Number of Circuits | 2 |
| Number of Elements | 2 |
| Operating Supply Current | 1.9mA |
| Output Current per Channel | 30mA |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Power Dissipation | 1W |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | LinCMOS™ |
| Slew Rate | 3.6V/µs |
| Supply Current | 4mA |
| Thickness | 3.9mm |
| Unity Gain Bandwidth Product | 1.7MHz |
| Voltage Gain | 87.23dB |
| Width | 6.35mm |
Compliance
| RoHS | Compliant |
Datasheet
Texas Instruments TLC272CP Datasheet
Download the complete datasheet for Texas Instruments TLC272CP to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
