32-bit Digital Signal Processor (DSP) featuring a C2000™ C28x Delfino™ core architecture operating at 150MHz with a Floating-Point Unit (FPU). This integrated circuit offers 512KB of FLASH memory and 68KB of RAM, supporting up to 16 analog-to-digital converter channels. It includes extensive interfaces such as I2C, SPI, CAN, UART, USART, SCI, and EMIF, along with 88 programmable I/Os and 8 PWM channels. Packaged in a 176-LQFP (1.4mm height, 24mm length, 24mm width) with a weight of 0.066886oz, this lead-free component operates between -40°C and 125°C.
Frequency150MHz
PackageLQFP
Quick Jump:
Technical Specifications
Texas Instruments TMS320F28335PGFA technical specifications.
General
Package/Case
LQFP
Core Architecture
C2000
Data Bus Width
32b
Density
512KB
Frequency
150MHz
Height
1.4mm
Interface
I2C, SPI, CAN, UART, USART, SCI, EBI/EMI
Lead Free
Lead Free
Length
24mm
Max Frequency
150MHz
Max Operating Temperature
125°C
Max Supply Voltage
1.995V
Memory Size
512KB
Memory Type
FLASH,
Min Operating Temperature
-40°C
Min Supply Voltage
1.805V
Number of A/D Converters
16
Number of ADC Channels
16
Number of Channels
16
Number of GPIO
88
Number of I/Os
88
Number of I2C Channels
1
Number of Programmable I/O
88
Number of PWM Channels
8
Number of SPI Channels
1
Number of Timers/Counters
3
Number of UART Channels
3
Oscillator Type
Internal
Package Quantity
1
Packaging
Tray
Peripherals
POR, PWM, WDT, DMA
Radiation Hardening
No
RAM Size
68KB
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
C2000™ C28x Delfino™
Watchdog Timer
Yes
Weight
0.066886oz
Width
24mm
Compliance
RoHS
Compliant
Datasheet
Texas Instruments TMS320F28335PGFA Datasheet
Download the complete datasheet for Texas Instruments TMS320F28335PGFA to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
