Texas Instruments
TPS62120DCNR
15V, 75mA, 96% efficiency Step-Down Converter with DCS-Control 8-SOT-23 -40 to 85
PackageSOT-23-8
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments TPS62120DCNR technical specifications.
General
Package/Case
SOT-23-8
Efficiency
96%
Lead Free
Lead Free
Max Input Voltage
15V
Min Input Voltage
2V
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Output Current
75mA
Max Output Voltage
5.5V
Min Output Voltage
1.2V
Mount
Surface Mount
Number of Outputs
1
Operating Supply Voltage
15V
Output Configuration
Positive
Output Current
75mA
Output Type
Adjustable
Output Voltage
5.5V
Packaging
Tape and Reel
Quiescent Current
11uA
Reach SVHC Compliant
No
RoHS Compliant
Yes
Synchronous Rectifier
Yes
Compliance
RoHS
Compliant
