Texas Instruments
UCC2808ADTR-2
low power current mode push-pull PWM with discharge transistor, 4.3/4.1V UVLO, -40°C to 85°C 8-SOIC -40 to 85
Frequency1MHz
PackageSOIC
MountingSurface Mount
Quick Jump:
Technical Specifications
Texas Instruments UCC2808ADTR-2 technical specifications.
General
Package/Case
SOIC
Clock Sync
No
Duty Cycle
50%
Fall Time
25ns
Lead Free
Lead Free
Max Duty Cycle
50%
Max Frequency
1MHz
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
15V
Mount
Surface Mount
Number of Output Phases
1
Number of Outputs
2
Output Configuration
Positive
Output Current
1A
Output Voltage
500mV
Package Quantity
2500
Packaging
Tape and Reel
Radiation Hardening
No
RoHS Compliant
Yes
Synchronous Rectifier
No
Topology
Push-Pull
Weight
0.002561oz
Compliance
RoHS
Compliant
Datasheet
Texas Instruments UCC2808ADTR-2 Datasheet
Download the complete datasheet for Texas Instruments UCC2808ADTR-2 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
