TT
84WR500KLF
Res Cermet Trimmer 500K Ohm 10% 0.25W(1/4W) 12(Elec)Turn 1.78mm (6.35 X 6.36 X 8.51mm) Gull Wing SMD Tube
Resistance500kR
Voltage Rating200V
MountingSurface Mount
Quick Jump:
Technical Specifications
TT 84WR500KLF technical specifications.
General
Depth
6.36mm
Lead Free
Lead Free
Length
6.35mm
Max Operating Temperature
150°C
Military Standard
Not
Min Operating Temperature
-65°C
Mount
Surface Mount
Number of Turns
12
Package Quantity
50
Packaging
Rail/Tube
Radiation Hardening
No
Resistance
500kR
Resistor Type
Cermet
RoHS Compliant
Yes
Series
84
Technology
CERMET
Termination
Gull Wing
Tolerance
10%
Type
Potentiometer
Voltage Rating
200V
Weight
0.4g
Compliance
RoHS
Compliant
Datasheet
TT 84WR500KLF Datasheet
Download the complete datasheet for TT 84WR500KLF to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
