United Chemi-Con
EKMG350ELL471MJ16S
Cap Aluminum Lytic 470uF 35V 20% (10 X 16mm) Radial 5mm 460mA 1000h 105°C Bulk
PackageRadial
Capacitance470uF
Voltage Rating35V
MountingThrough Hole
Quick Jump:
Technical Specifications
United Chemi-Con EKMG350ELL471MJ16S technical specifications.
General
| Capacitance | 470uF |
| Package/Case | Radial |
| Construction | RADIAL |
| Lead Diameter | 0.6mm |
| Lead Free | Lead Free |
| Lead Pitch | 5mm |
| Length | 16mm |
| Life (Hours) | 1000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Package Quantity | 2000 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ripple Current | 460mA |
| RoHS Compliant | Yes |
| Series | KMG |
| Termination | Radial |
| Tolerance | 20% |
| Voltage Rating | 35V |
| DC Rated Voltage | 35V |
Compliance
| RoHS | Compliant |
Datasheet
United Chemi-Con EKMG350ELL471MJ16S Datasheet
Download the complete datasheet for United Chemi-Con EKMG350ELL471MJ16S to view detailed technical specifications.
