This 47uF tantalum capacitor from Vishay features a 6.3V voltage rating and 20% tolerance. It has a molded package and is designed for surface mount applications. The capacitor has a maximum operating temperature of 125°C and a minimum operating temperature of -55°C. It is lead free and RoHS compliant.
PackageMolded
Capacitance47uF
Voltage Rating6.3V
MountingSurface Mount
Quick Jump:
Technical Specifications
Vishay 593D476X06R3B2TE3 technical specifications.
General
| Capacitance | 47uF |
| Package/Case | Molded |
| Construction | Flat |
| Depth | 2.8mm |
| Dissipation Factor | 6% |
| ESR (Equivalent Series Resistance) | 550mR |
| Features | General Purpose |
| Height | 1.9mm |
| Lead Free | Lead Free |
| Length | 3.5mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Packaging | Tape and Reel |
| Polarity | Polar |
| RoHS Compliant | Yes |
| Series | TANTAMOUNT®, 593D |
| Tolerance | 20% |
| Voltage Rating | 6.3V |
| DC Rated Voltage | 6.3V |
Compliance
| RoHS | Compliant |
Datasheet
Vishay 593D476X06R3B2TE3 Datasheet
Download the complete datasheet for Vishay 593D476X06R3B2TE3 to view detailed technical specifications.
No datasheet is available for this part.
