Technical Specifications
Vishay BAT54WS-E3-08 technical specifications.
General
| Average Rectified Current | 200mA |
| Forward Current | 200mA |
| Lead Free | Lead Free |
| Max Forward Surge Current (Ifsm) | 600mA |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 150mW |
| Max Repetitive Reverse Voltage (Vrrm) | 30V |
| Max Reverse Voltage (DC) | 30V |
| Max Surge Current | 600mA |
| Mount | Surface Mount |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Peak Non-Repetitive Surge Current | 600mA |
| Power Dissipation | 150mW |
| Reach SVHC Compliant | Unknown |
| Reverse Recovery Time | 5ns |
| Reverse Recovery Time-Max | 5ns |
| RoHS Compliant | Yes |
| Weight | 0.000152oz |
Compliance
| RoHS | Compliant |
Datasheet
Vishay BAT54WS-E3-08 Datasheet
Download the complete datasheet for Vishay BAT54WS-E3-08 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
