Surface mount thick film fixed resistor with 2MΩ resistance and 1% tolerance. Features a 0805 case size (2mm x 1.25mm x 0.45mm) and a 150V DC rating. Designed for automotive applications with AEC-Q200 qualification, operating from -55°C to +155°C. Power dissipation is 125mW, with a temperature coefficient of 100ppm/°C. Halogen-free and RoHS compliant.
Package0805
Resistance2MR
Voltage Rating150V
Quick Jump:
Technical Specifications
Vishay CRCW08052M00FKEA technical specifications.
General
Case Code (Imperial)
0805
Case Code (Metric)
2012
Package/Case
0805
Construction
Rectangular
Contact Plating
Tin
Depth
1.25mm
Features
Automotive AEC-Q200
Height
0.45mm
Lead Free
Lead Free
Length
2mm
Max Operating Temperature
155°C
Max Power Dissipation
125mW
Military Standard
Not
Min Operating Temperature
-55°C
Number of Terminations
2
Package Quantity
10
Packaging
Tape and Reel
Radiation Hardening
No
Reach SVHC Compliant
Unknown
Resistance
2MR
Resistance Tolerance
1%
Resistor Type
Thick Film
RoHS Compliant
Yes
Series
CRCW
Size Code
0805
Technology
THICK FILM
Termination
SMD/SMT
Tolerance
1%
Voltage Rating
150V
DC Rated Voltage
150V
Weight
0.000194oz
Width
0.049inch
Compliance
RoHS
Compliant
Datasheet
Vishay CRCW08052M00FKEA Datasheet
Download the complete datasheet for Vishay CRCW08052M00FKEA to view detailed technical specifications.
