CMOS multiplexer/demultiplexer IC featuring 4 channels, 4 circuits, 4 inputs, and 4 outputs. Operates with single or dual supply voltages ranging from 7V to 22V, with a maximum supply voltage of 36V. Offers a drain-to-source resistance of 85 Ohms and a maximum power dissipation of 900mW. Packaged in a 16-pin SOIC surface-mount package with dimensions of 10mm length, 4mm width, and 1.55mm height.
PackageSOIC
MountingSurface Mount
Power900mW
Quick Jump:
Technical Specifications
Vishay DG441DY technical specifications.
General
Package/Case
SOIC
Drain to Source Resistance
85R
Dual Supply Voltage
15V
Height
1.55mm
Length
10mm
Max Dual Supply Voltage
22V
Min Dual Supply Voltage
7V
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Power Dissipation
900mW
Max Supply Current
100uA
Max Supply Voltage
36V
Min Supply Voltage
13V
Mount
Surface Mount
Number of Channels
4
Number of Circuits
4
Number of Inputs
4
Number of Outputs
4
Package Quantity
500
Packaging
Rail/Tube
Power Dissipation
900mW
RoHS Compliant
No
Supply Type
Single, Dual
Weight
0.023492oz
Width
4mm
Compliance
RoHS
Not Compliant
Datasheet
Vishay DG441DY Datasheet
Download the complete datasheet for Vishay DG441DY to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
