Solid tantalum capacitor with 4.7µF capacitance and 20V DC rated voltage. Features 10% tolerance, 1.8Ω ESR, and a maximum operating temperature of 125°C. Surface mountable in a 3216 metric (1206 imperial) case, this component offers a ripple current of 200mA and a leakage current of 900nA. Packaged on tape and reel for automated assembly.
Package1206
Voltage20V
Capacitance4.7uF
Voltage Rating20V
Quick Jump:
Technical Specifications
Vishay TR3A475K020C1800 technical specifications.
General
Capacitance
4.7uF
Case Code (Imperial)
1206
Case Code (Metric)
3216
Package/Case
1206
Construction
Flat
Depth
1.6mm
Dielectric Material
Tantalum
Dissipation Factor
6%
ESR (Equivalent Series Resistance)
1.8R
Features
General Purpose
Height
1.6mm
Lead Free
Lead Free
Leakage Current
900nA
Length
3.2mm
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount, PCB
Package Quantity
2000
Packaging
Tape and Reel
Q Factor
6
Radiation Hardening
No
Reach SVHC Compliant
Unknown
Ripple Current
200mA
RoHS Compliant
Yes
Series
TANTAMOUNT®, TR3
Termination
SMD/SMT
Tolerance
10%
Voltage
20V
Voltage Rating
20V
DC Rated Voltage
20V
Width
1.6mm
Compliance
RoHS
Compliant
Datasheet
Vishay TR3A475K020C1800 Datasheet
Download the complete datasheet for Vishay TR3A475K020C1800 to view detailed technical specifications.
