Solid Tantalum Capacitor, 22µF capacitance, 35V DC rated voltage, and 20% tolerance. Features 400mΩ ESR, 6% dissipation factor, and 7.7µA leakage current. Operates from -55°C to 125°C, with a ripple current rating of 610mA. Packaged in a 7343-31 (2917 imperial) SMD case with inward leads, measuring 7.3mm x 4.3mm x 2.8mm. RoHS compliant and lead-free.
Package2917
Voltage35V
Capacitance22uF
Voltage Rating35V
Quick Jump:
Technical Specifications
Vishay TR3D226M035C0400 technical specifications.
General
| Capacitance | 22uF |
| Case Code (Imperial) | 2917 |
| Case Code (Metric) | 7343 |
| Package/Case | 2917 |
| Construction | Flat |
| Depth | 4.3mm |
| Dielectric Material | Tantalum |
| Dissipation Factor | 6% |
| ESR (Equivalent Series Resistance) | 400mR |
| Height | 2.8mm |
| Lead Free | Lead Free |
| Leakage Current | 7.7uA |
| Length | 7.3mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| Ripple Current | 610mA |
| RoHS Compliant | Yes |
| Series | TR3 |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage | 35V |
| Voltage Rating | 35V |
| DC Rated Voltage | 35V |
| Width | 4.3mm |
Compliance
| RoHS | Compliant |
Datasheet
Vishay TR3D226M035C0400 Datasheet
Download the complete datasheet for Vishay TR3D226M035C0400 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
