Technical Specifications
Vishay TSOP31138 technical specifications.
General
Height
12.5mm
Length
10mm
Max Operating Temperature
85°C
Min Operating Temperature
-25°C
Max Power Dissipation
10mW
Max Supply Voltage
5.5V
Min Supply Voltage
2.5V
Mount
Through Hole
Operating Supply Current
350uA
Orientation
Side View
Output Current
5mA
Package Quantity
1000
Packaging
Rail/Tube
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Sensing Distance
45m
Supply Current
350uA
Viewing Angle
45°
Width
5.8mm
Compliance
RoHS
Compliant
Datasheet
Vishay TSOP31138 Datasheet
Download the complete datasheet for Vishay TSOP31138 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
