Frequency36kHz
Current450uA
MountingThrough Hole, PCB
Power10mW
Quick Jump:
Technical Specifications
Vishay TSOP31236 technical specifications.
General
Frequency
36kHz
Height
12.5mm
Lead Free
Lead Free
Length
10mm
Max Operating Temperature
85°C
Min Operating Temperature
-25°C
Max Supply Voltage
5.5V
Min Supply Voltage
2.5V
Mount
Through Hole, PCB
Operating Supply Current
350uA
Orientation
Side View
Output Current
5mA
Package Quantity
1000
Packaging
Rail/Tube
Power Dissipation
10mW
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Sensing Distance
45m
Supply Current
450uA
Viewing Angle
45°
Wavelength
950nm
Width
5.8mm
Compliance
RoHS
Compliant
Datasheet
Vishay TSOP31236 Datasheet
Download the complete datasheet for Vishay TSOP31236 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
