Ferrite chip EMI/RFI filter for data lines, featuring a 120 Ohm impedance at 100MHz and a 1 Henry inductance. This surface-mount device supports a 3A current rating with a low 30mOhm DC resistance. Encased in an EIA 0805 (2012 metric) SMD package, it operates across a wide temperature range from -55°C to 125°C. The component is RoHS compliant and designed for efficient signal integrity in electronic circuits.
PackageSMD/SMT
Current Rating3A
MountingSurface Mount
Inductance1H
Quick Jump:
Technical Specifications
Wurth Electronics 742792023 technical specifications.
General
Case Code (Imperial)
0805
Case Code (Metric)
2012
Package/Case
SMD/SMT
Core Material
Ferrite
Current Rating
3A
DC Resistance (DCR)
30mR
Depth
1.2mm
Height
0.9mm
Impedance
120R
Inductance
1H
Lead Free
Lead Free
Length
2mm
Max Current Rating
3A
Max DC Current
3A
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Number of Lines
1
Package Quantity
1
Packaging
Tape and Reel
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
WE-CBF
Shielding
Unshielded
Termination
SMD/SMT
Test Frequency
100MHz
Tolerance
25%
Weight
0.000388oz
Width
1.2mm
Compliance
RoHS
Compliant
Datasheet
Wurth Electronics 742792023 Datasheet
Download the complete datasheet for Wurth Electronics 742792023 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
