Frequency100kHz
MountingSurface Mount
Inductance15uH
Quick Jump:
Technical Specifications
Wurth Electronics 750311458 technical specifications.
General
DC Resistance (DCR)
35mR
Depth
12.7mm
Frequency
100kHz
Height - Seated (Max)
12.7mm
Inductance
15uH
Input Current
4A
Isolation Voltage
2.5kV
Length
17.75mm
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Mount
Surface Mount
Output Voltage
3.3V
Package Quantity
1
Packaging
Cut Tape
Primary Inductance
15H
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Series
WE-FB
Turns Ratio
3:1
Width
13.46mm
Compliance
RoHS
Compliant
Datasheet
Wurth Electronics 750311458 Datasheet
Download the complete datasheet for Wurth Electronics 750311458 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
