Shielded, right-angle male SCSI connector with 50 positions and 50 contacts. Features IDC termination with a 1.27mm pitch, copper contacts with gold plating, and a steel body. Rated for 1A current and operates between -20°C and 85°C. Housing is black, UL94 V-0 flammability rated, and lead-free.
Current Rating1A
MountingFree Hanging, Cable
Quick Jump:
Technical Specifications
3M 10150-6000EC technical specifications.
General
Approvals
UL
Body Material
Steel
Contact Material
Copper
Contact Plating
Gold
Current Rating
1A
Depth
9.1mm
Features
Shielded
Flammability Rating
UL94 V-0
Gender
Male
Housing Color
Black
Lead Free
Lead Free
Lead Length
3m
Length
41.1mm
Max Current Rating
1A
Max Operating Temperature
85°C
Min Operating Temperature
-20°C
Mount
Free Hanging, Cable
Number of Contacts
50
Number of Ports
1
Number of Positions
50
Number of Rows
2
Orientation
Right Angle
Package Quantity
100
Pitch
1.27mm
Plating
Nickel
RoHS Compliant
Yes
Sensing Distance
3m
Series
101
Termination
IDC
Weight
1lb
Width
12.7mm
Compliance
RoHS
Compliant
