The EL302P is a digital power supply with a maximum output voltage of 30V and a maximum output current of 2A. It has a maximum power dissipation of 60W and operates on an input voltage of 230V AC. The supply has a maximum operating temperature of 40°C and a minimum operating temperature of 5°C. It is part of the EL-R series and is not SVHC compliant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Aim-Tti EL302P datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Aim-Tti EL302P technical specifications.
| Display Type | Digital |
| Height | 160mm |
| Length | 295mm |
| Max Operating Temperature | 40°C |
| Min Operating Temperature | 5°C |
| Max Output Current | 2A |
| Max Output Voltage | 30V |
| Min Output Voltage | 0V |
| Max Power Dissipation | 60W |
| Max Supply Voltage (AC) | 230V |
| Min Supply Voltage (AC) | 115V |
| Number of Characters | 8 |
| Number of Outputs | 1 |
| Operating Supply Voltage | 230V |
| Output Connector | Binding Post Terminal |
| Output Current | 2A |
| Output Voltage | 30V |
| Reach SVHC Compliant | No |
| Series | EL-R |
| Weight | 4.4kg |
| Width | 140mm |
| RoHS | Compliant |
