Alpha Wire
5108C-SL005
ALPHA WIRE 5108C SL005 Multicore Screened Cable, Xtra Guard 1, Grey, 8 Core, 22 AWG, 0.35 mm, 100 ft, 30.5 m
Package100
Voltage Rating300V
MountingCable
Quick Jump:
Technical Specifications
Alpha Wire 5108C-SL005 technical specifications.
General
| Approvals | UL, CSA, CE |
| Package/Case | 100 |
| Color | Grey |
| Conductor Material | Copper |
| Insulation Material | PVC |
| Jacket Material | PVC |
| Length | 100foot |
| Max Operating Temperature | 75°C |
| Min Operating Temperature | -20°C |
| Mount | Cable |
| Number of Conductors | 8 |
| Number of Cores | 8 |
| Outside Diameter | 6.86mm |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 5108 |
| Shielding | Shielded |
| Stranding | 7 x 30 |
| Voltage Rating | 300V |
| Voltage Rating (AC) | 300V |
| Weight | 5.06lb |
| Wire/Cable Gauge | 22AWG |
Compliance
| RoHS | Compliant |
Datasheet
Alpha Wire 5108C-SL005 Datasheet
Download the complete datasheet for Alpha Wire 5108C-SL005 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
