Technical Specifications
Alpha Wire TFT20030NA001 technical specifications.
General
| Color | Natural |
| Flammability Rating | UL94 V-0 |
| Inside Diameter | 0.01inch |
| Lead Free | Lead Free |
| Length | 1000foot |
| Material | PTFE, Polytetrafluoroethylene |
| Max Operating Temperature | 260°C |
| Min Operating Temperature | -75°C |
| Outside Diameter | 0.028inch |
| Package Quantity | 1 |
| Packaging | Spool |
| Series | TFT-200 |
| Thickness | 229um |
| Weight | 1lb |
Compliance
| RoHS | Compliant |
Datasheet
Alpha Wire TFT20030NA001 Datasheet
Download the complete datasheet for Alpha Wire TFT20030NA001 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
